2019-2023 Ford Ranger Wheel & Tire Guide

Note:

Check out the 1983-2011 Ford Ranger Wheel Fitment Guide if you have a 1983-2011 Ford Ranger.

2019-2022 Ford Ranger Stock Wheels & Tire Specs

2019+ Ford Ranger Stock Tire Sizes:

16 x 7.0-inch Alloy Wheel (Steel in 2019)

255/70R16 A/S (30.1x10x16)

17 x 8.0-inch Alloy Wheel

255/65R17 A/S (30.1x10x17)
255/65R17 A/T (30.1x10x17)
265/65R17 A/T OWL (30.1x10x17)
LT265/65R17 A/T OWL (30.1x10x17)

18 x 8.0-inch Alloy Wheel

265/60R18 A/S (30.5×10.4×18)
265/60R18 A/T (30.5×10.4×18)
265/60R18 A/T OWL (30.5×10.4×18)

* A/S = All Season A/T = All Terrain OWL = Outlined White Letter

2019+ Ford Ranger Wheel Specifications:

Center Bore: 93.1 mm
Bolt Pattern: 6×139.7 (6×5.5)
Wheel Offset: +55mm offset
Wheel Tightening Torque: 135 Nm
Thread Size: M12 x 1.5

6×139.7 / 6×5.5 Bolt Pattern Is Common:

The 6 lug 6×139.7 / 6×5.5 bolt pattern is common on many vehicles such as the 6 lug Toyota 4-Runner, FJ Cruiser, Sequoia, Tacoma, and Tundra, Nissan Armada, Titan, Frontier, Pathfinder, and Xterra, GMC 1500, Sierra, Yukon, Canyon, Hummer H3, H3T, and H3X, and Chevrolet Colorado, Avalanche, 1500, Suburban, Silverado, Cadillac Escalade, Ford Ranger and brand new Ford Bronco 2021+

The Chevy 1500 trucks have been using this pattern in their 4×4 models since 1967.

The difference between the various 6×139.7 / 6×5.5 wheels range from width, backspacing, and center bore. You might be ok with the width and back spacing (wheel offset), but the Ranger requires a center bore of at least 93.1 mm.

Measuring Wheels

Wheel Offset:

Wheel offset is considered the distance from the center of your wheel to its mounting surface, which is the part of the wheel that comes together with the rotor on installation. This measurement helps define where the wheel will sit and is typically measured in millimeters.

The higher the offset, the more inward the wheel will install, leading to a narrower vehicle stance and less clearance between the suspension and your tires inside edge. The lower the offset, the more outward it will install which leads to a wider vehicle stance and more clearance between tire and suspension. This, generally, is better for those who have added a suspension lift along with larger tires.

There are three types of offset – zero offset, positive offset, and negative offset.

Zero Offset: In a wheel with zero offset, the mounting surface of the wheel is on the centerline. The centerline is the centermost point of your wheel, if you were cutting it in half vertically.

Positive Offset: In a wheel with positive offset, the mounting surface of the wheel is to the outside of the wheel (on the street side). This is the most common scenario for newer, OEM setups. This offers maximum backspacing.

Negative Offset: In a wheel with negative offset, the mounting surface of the wheel is tucked back closer to the inside edge of the wheel, offering less backspacing, and a more “dished” wheel, popular in show cars and trucks.

Example of Wheel Offset:

(Left) Positive: When the mounting surface is in front of the centerline and closer to the outside rim than the back part of the wheel.
(Middle) Zero: When the mounting surface is right where the centerline is; this gives your wheels a centered look.
(Right) Negative: When the mounting surface is recessed past the centerline; this gives your wheels a deep 3D look.

Wheel Backspacing:

Backspacing: Backspacing refers to how much space there is between the back side of the wheel and the mounting surface of the wheel.

Rims with more backspace have less inside wheel clearance and can potentially rub up against the vehicle’s suspension, steering system and other vehicle components. Less backspace on a wheel means more inside wheel clearance and little risk of rubbing.

How To Measure Wheel Backspacing:

To measure backspacing, lay the wheel facedown. (Pro Tip: use a soft surface to protect the wheel face.) Place a solid, flat item, such as a board, across the wheel so that there’s a flat surface touching both sides of the wheel. Then, using a ruler or tape measure, measure the distance from the mounting surface to the base of the object.

Recommended Wheel Offset Ford The 2019+ Ford Ranger:

Wheels I’m finding recommended to fit my application show a 0mm wheel offset.

What Will Fit Your Ford Ranger

What’s The Biggest Tire I Can Fit On A Stock Ranger?

I put a set of 265/70/17 mud terrains on a 2019 Ford Ranger FX4. The tires fit and didn’t rub on the intrusions beams (crash bars).

Stock: 265/65/17 (30.40×10.40×17)
Cooper Discoverer STT PRO’s: 265/70/17 (31.93×10.70×17)

See more at ‘Largest Tire On A 2019 Ford Ranger Without A Lift‘

The new tires are 1.53-inches taller than stock, so the truck picked up 3/4″ of ground clearance.

What’s The Biggest Tire I Can Fit With A 2.0 – 2.5 Inch Leveling Kit?

Ready Lift states that their 2-inch Leveling Kit Will Accept:

18×9 wheels with +18 offset and 265/60R18 tires (30.5×10.4×18)
18×9 wheels with +30 offset and 265/65R18 tires (31.6×10.4×18)
20×9 wheels with +18 offset and 275/55R20 tires (31.9×10.8×20)
20×9 wheels with +30 offset and 275/55R20 tires (31.9×10.8×20)

Rough Country States that their 2.5-inch leveling kit:

“This 2.5” suspension system was developed using a 265/70R17 (31.6×10.4×17), 255/75R17 (32.1x10x17) or 265/65R18 (31.6×10.4×18) tire on factory wheels. Aftermarket wheels must have a minimum of 93.1mm center bore, and maximum 6.5” back spacing. Wheels with less than 6.5” backspacing may require slight trimming. 9” wide wheels will require trimming.”

Superlift states that their 2-inch leveling kit with fit:

265/70/17 (31.6×10.4×17) tire on a factory wheel
255/75/17 (32.1x10x17) tire on a factory wheel
265/65/18 (31.6×10.4×18) tire on a factory wheel
265/60/18 (30.5×10.4×18) tire on a 18×9 wheel with 6.5-inch backspacing and +18mm offset
265/60/18 (30.5×10.4×18) tire on a 18×9 wheel with 6.5-inch backspacing and +30mm offset
275/55/20 (31.9×10.8×20) tire on a 20×8 wheel with 5.5 – 6.5-inch backspacing and +18mm offset
275/55/20 (31.9×10.8×20) tire on a 20×9 wheel with 6.5-inch backspacing and +30mm offset
285/55/20 (32.3×11.2×20) tire on a 20×9 wheel with 5-inch backspacing and +30mm offset

*20-Inch wheel requires 93.1mm center bore

*20×9 aftermarket may require some trimming

Skyjacker states that their 2.5-inch leveling kit:

Has a max tire size of 265/65R18 (31.6×10.4×18)
Aftermarket Wheels Must Have a Minimum of 93.1mm Center Bore and Maximum 6.5” Backspacing.
Wheels with Less Than 6.50 Inch Backspacing May Require Slight Trimming.
Nine (9) Inch Wide Wheels Will Require Trimming.

What’s The Biggest Tire I Can Fit With A 3.0-Inch Leveling Kit?

ReadyLIFT states that their 3.0-inch leveling kit will fit:

18×9 +18 offset 285/60R18 (31.5×11.2×18)
18×9 +30 offset 275/65R18 (32.1×10.8×18)
20×9 +18 offset 275/55R20 (31.9×10.8×20)
20×9 +30 offset 285/55R20 (32.3×11.2×20)

What’s The Biggest Tire I Can Fit With A 3.5-Inch Suspension Lift Kit?

BDS Suspension states:

275/65r w/20×9 and 6.18″ backspacing (34.1×10.8×20)
285/65r w/18×9 and 5.5-5.75″ backspacing (32.6×11.2×18)
305/55r w/20×9 and 5″ backspacing (33.2x12x20)

*Trimming may be required*

Tire & Wheel Combinations For 3.5 inch Kit With Spacer

285/70r17 w/17″ and stock back spacing (32.7×11.2×17)
285/65r18 w/18″ and stock back spacing (32.6×11.2×18)
275/65r18 w/18×9 and 6.125″ back spacing (32.1×10.8×18)

*Trimming may be required*

Fabtech states:

Use 33/12.50R18 tires w/ 18×9 wheels w/ 5″ BS w/ minor trimming
Use 33/12.50R20 tires w/ 20×9 wheels w/ 5″ BS w/ minor trimming

Rough Country states:

“This kit was developed using a 285/55/r20 for a no rub on a 20 x 9 +30 offset.”

Skyjacker states:

Max Tire Size – 285/65R18 (32.6×11.2×18)
Wheel – 18 x 8
Aftermarket Wheels Must Have a Minimum of 93.1mm Center Bore & Maximum 6.5” Backspacing.
Wheels with Less Than 6.50 Inch Backspacing May Require Slight Trimming.
Nine (9) Inch Wide Wheels Will Require Trimming.

Superlift states:

This kit was developed using a 285/70 R17. Any larger or wider tire & wheel combination other than listed may require vehicle trimming.

285/70R17 (32.7×11.2×17) on 17×9 Stock Wheel
285/65R18 (32.6×11.2×18) on 18×9 Stock Wheel
285/55R20 (32.3×11.2×20) on 20×9 Wheel With +30MM Offset

What’s The Biggest Tire I Can Fit With A 6-Inch Suspension Lift?

BDS Suspension States:

35×12.50 tire on 20×9 wheel with 5.5-6″ back spacing
305/65r18 (33.6x12x18) tire on 18×9 wheel with 5″ back spacing (33.6x12x18)
33×12.50 tire on 17×9 / 18×9 / 20×9 wheel with 4.5″ back spacing

*Trimming may be required*

Rough Country states:

“This 6-inch suspension system was developed using a 305/55-R20 (33.2x12x20) tire, on a 20 x 9 +12mm wheel. We recommend aftermarket wheels to not exceed 6 inches of back spacing. The factory 17- and 18-inch wheels are not applicable with this kit.”

Intrusion Beams

The anti-intrusion beams on new Ford trucks are intended for collision safety reasons. While important, the factory beams do not provide adequate room for tire clearance when installing larger tires after adding a lift kit. Some companies offer replacement intrusion beams that allow more room for larger tires. It may be necessary to replace your factory intrusion beams with new ones designed to provide more tire clearance.

See Readylift Intrusion Beams.
